Why H.264/MPEG-4 AVC

H.264 or MPEG-4, Advanced Video Encoding (MPEG-4 AVC) is a block-oriented motion-compensation-based video compression standard. It supports resolutions up to 8192×4320, including 8K UHD.

The intent of the H.264/AVC project was to create a standard capable of providing good video quality at substantially lower bit rates than previous standards, without increasing the complexity of design so much that it would be impractical or excessively expensive to implement. An additional goal was to provide enough flexibility to allow the standard to be applied to a wide variety of applications on a wide variety of networks and systems, including low and high bit rates, low and high resolution video, broadcast, DVD storage, RTP/IP packet networks, and ITU-T multimedia telephony systems. The H.264 standard can be viewed as a “family of standards” composed of a number of different profiles. A specific decoder decodes at least one, but not necessarily all profiles. The decoder specification describes which profiles can be decoded. H.264 decoder is typically used for lossy compression, although it is also possible to create truly lossless-coded regions within lossy-coded pictures or to support rare use cases for which the entire encoding is lossless.

Why H.264/MPEG-4 AVC

H.264 was developed by the ITU-T Video Coding Experts Group (VCEG) together with the ISO/IEC JTC1 Moving Picture Experts Group (MPEG). The project partnership effort is known as the Joint Video Team (JVT). The ITU-T H.264 standard and the ISO/IEC MPEG-4 AVC standard (formally, ISO/IEC 14496-10 – MPEG-4 Part 10, Advanced Video Coding) are jointly maintained so that they have identical technical content. The final drafting work on the first version of the standard was completed in May 2003, and various extensions of its capabilities have been added in subsequent editions. High Efficiency Video Coding (HEVC), a.k.a. H.265 and MPEG-H Part 2 is a successor to H.264/MPEG-4 AVC developed by the same organizations, while earlier standards are still in common use.

H.264 is perhaps best known as being one of the video encoding standards for Blu-ray Discs; all Blu-ray Disc players must be able to decode H.264. It is also widely used by streaming Internet sources, such as videos from Vimeo, YouTube, and the iTunes Store, Web software such as the Adobe Flash Player and Microsoft Silverlight, and also various HDTV broadcasts over terrestrial (ATSC, ISDB-T, DVB-T or DVB-T2), cable (DVB-C), and satellite (DVB-S and DVB-S2).

H.264 is protected by patents owned by various parties. A license covering most (but not all) patents essential to H.264 is administered by patent pool MPEG LA.[3] Commercial use of patented H.264 technologies requires the payment of royalties to MPEG LA and other patent owners. MPEG LA has allowed the free use of H.264 technologies for streaming Internet video that is free to end users, and Cisco Systems pays royalties to MPEG LA on behalf of the users of binaries for its open source H.264 streaming encoder.
