ORIVISION Uncompressed HDMI Optical Firber Extender

【Uncompressed Transmission】All digital, uncompression, zero delay, strong compatibility with no delay and no loss, audio and video synchronous transmission

【HD Resolution】Resolution up to 1920x1080@60fps(RGB 4:4:4 YUV4:4:4 YUV:4:2:2 YUV4:2:0), HDMI 1.4 and HDCP 1.4 Compliant

【10KM Extreme Long Transmission】Extend HDMI signal up to 10KM over a single mode fiber  one core cable; or extend HDMI signal up to 300M over a multimode dual core cable; 20KM-80KM distance can be customised

【Excellent Quality】Supports 7.1-channel PCM surround sound and compressed audio, support analog stereo audio signal transmission

【Support RS232】Support serial port data transmission, adaptive baud rate

【Plug and Play】Simple to install, plug and play, no setup or configuration needed


HDMI Optical Fiber Extender
HDMI Optical Fiber Extender
  • Uncompressed Transmission Up to 10KM

  • Maximum resolution : 1920×1080@60HZ

  • Support RGB 4:4:4 YUV4:4:4 YUV:4:2:2 YUV4:2:0

  • Supports 7.1-channel PCM surround sound and compressed audio

  • plug and play, no setting required

Uncompressed HDMI Optical Fiber Extender

OH1001 is a fiber-based extender designed to extend uncompressed HD Video signals up to 300m(Using Multimode Dual Core SFP) or 10km(Using Single model core SFP) over duplex fiber cables.

It has excellent image processing and transmission capabilities, making signal transmission smoother and more stable. It is a reliable, high-performance and efficient way to extend HDMI signals.

It is widely used in exhibitions, subway, radio and television, video conferencing, medical teaching, educational recording and broadcasting, projection integrat ion and other industries wi th high video requirements.


Support KVM Optional: ZY-OKH1001


Uncompressed HDMI Optical Fiber Extender
Uncompressed Transmission

HDMI to fiber converter can transmit the uncompressed signals up to 10km with no delay and no loss, audio and video synchronous transmission, data rates up to 10Gbps.

Uncompressed Transmission
Professional for HDMI HD Video Extender

Delivers UHD picture quality at resolutions up to 1920 x 1080 @60Hz. Support RGB 4:4:4 YUV4:4:4 YUV:4:2:2 YUV4:2:0. Enjoy bright, clear video with accurate color rendition and sharpness, even when long distance transmission.

Professional for HDMI HD Video Extender
Point to Point Transimission, Up to 10KM

Extend HD signals up to 10KM over a single mode one core fiber cable,

or extender HD signals up to 300 meters over a multimode dual core fiber cable.

Transmission 20KM/40KM/60KM/80KM can be customised.


Point to Point Transimission, Up to 10KM
AUDIO CAPABILITIES

Supports 7.1-channel PCM surround sound and compressed audio, support analog stereo audio signal transmission

AUDIO CAPABILITIES
Plug and Play, Hassle-Free Installation

Plug-and-play operation with no software required for easy, immediate installation

Plug and Play, Hassle-Free Installation
Support OEM ODM

OEM: Free print company logo by laser print; MOQ≥1 unit

ODM: Pls send your requirements to us. (info@orivision.cn)

Support OEM ODM

Parameters of Uncompressed HDMI Optical Firber Extender


NameHDMI Uncompression Fiber Extender
ModelZY-OH1001
Interface StandardHDMI-A, HDMI 1.4
Pixel bandwidth300MHz
Interface bandwidth6.75Gbps
Resolutions1920×1080@60HZ, 720p/60Hz,
1080i/60Hz, 1080p/30Hz and so on
HDMI CableLess than 10M
If a balanced cable is used for a resolution of
1920X1080@60Hz or above, it can be up to 30M
Interface3.5mm Stereo audio socket
formatindependent stereo,forward stereo
InterfacePhoenix terminal
Baud rate4800-115200
Signal directionForward transmission (Bidirectional transmission option)
InterfaceLC
TypesSFP Single mode
WavelengthSingle mode 1310nm, multimode:850m
Bandwidth10Gbps
Distance10KM (default single mode)
20KM 40KM 60KM 80KM (Optional)
300m (multimode)
Attenuation——5db
Temperature0 ~ +40° C
Humidity20 ~ 90 %
Power Consumption4W/Unit
Power supplyDC 12V1A
Dimensions169*111*24mm (Length * width * height)
Weight0.45KG/unit





Diagram of Uncompressed HDMI Optical Firber Extender

It is ideal for a wide range of applications requiring long distance transmission of high resolution content with the highest quality.
