Brand: ORIVISION
Model: ZY-UCH501
Input Interface: HDMI, Audio
Output Interface: USB3.0, HDMI, Audio
HDMI Input Resolution: Up to 3840*2160@30hz
USB Out-put Resolution: Up to 3840*2160@30hz
Support System: Windows, Linux and Mac OS
Software Support: Most sofware: VLC,OBS,Amcap,etc.
Warranty: 1 Year
Certificate: CE & FCC & Rohs
Professional HDMI to USB3.0 Capture Card
This is a 4K@30 audio and video capture card that supports the conversion of HDMI audio and video signals to USB3.0 data output. Through third-party software, audio and video data collection and recording are completed. The collected audio and video is collected in the form of documents Save, also support upload to third-party software for video live broadcast. This product supports HDMI audio separation, and supports external microphone mixing input. No need to install driver software, you can directly use the video capture card to connect with the computer.
Supports HDMI audio separation, and supports external microphone mixing input
Support System: Windows, Linux and Mac OS
Support most acquisition software,
such as VLC/OBS/Amcap, etc
Such as youtube/facebook/twitch/stream, etc
HDMI Input ResolHDMI Input Resolution: Up to 3840*2160@30hz
USB Out-put Resolution: Up to 3840*2160@30hz
Without external power supply, compact and portable.
With up to 360MB/s transfer speed, to meet your need from capture to display with low latency.
Apply to game live streaming, live broadcasting, online classes, video conference, etc.
| Product Name | 4K@30 HDMI Video Capture Card |
| Model | UCH501 |
| Input Interface | HDMI, Audio |
| Out-put Interface | USB3.0, Audio, HDMI |
| Video Input | 1 channel HDMI video signal input |
| Audio Input | When 1 channel LPCM audio & HDMI video signal input，1 channel external audio signal can be input simultaneously（1 channel 3.5mm mic audio input or 1 channel 3.5mm linear audio input） |
| Video Output | USB3.0 compatible with USB2.0 video signal output，1channel HDMI loop out |
| Audio Output | 1 channel 3.5mm audio signal output |
| Video Output Frame | USB3.0 support 3840x2160@30FPS (NV12)， 2560x1600 and below formats support 60 FPS |
| HDMI Input Format | Conform to HDMI 1.4a standard，support 2160P30 8-bit,(NV12,YUV) |
| Transmission Rate | HDMI:165MHZ |
| Software Support | Most sofware: VLC,OBS,Amcap,etc |
| USB Support | Conform to USB Video and UVC standard; Conform to USB Audio UAC standard; |
| Output Color Space | YUY2、NV12 |
| Support System | Windows, Linux and Mac OS |
| Power | Without external power supply, compact and portable. |
| Operating temperature | 0°C ~ 50°C |
| Size (L*W*H) | 88x70x25(mm) |
| Weight | 0.1kg |
Apply to game live streaming, live broadcasting, online classes, video conference, etc.
